SMC - Magnetically Coupled Rodless Cylinders

SMC – Magnetically Coupled Rodless Cylinder CY3

Further improvements have been made on the CY1 series.
The mounting dimensions are the same as those of the CY1 series. Upgraded bearing performance and reduced sliding resistance
NPT thread and G thread are available as standard.

Type	Series	Action	Bore size (mm)
Basic	CY3B	Double acting	6, 10, 15, 20, 25, 32, 40, 50, 63
Direct mount	CY3R	Double acting	6, 10, 15, 20, 25, 32, 40, 50, 63

SMC – Magnetically Coupled Rodless Cylinder CY1S

Weight: Max. 15% reduction (0.96 kg: Existing model 1.13 kg)
Overall length: Max. 15 mm shorter (240 mm: Existing model 255 mm)
Improved durability: Lube-retainers are mounted on the internal and external surfaces of the cylinder tube to maintain lubrication.
The adjustment bolt improves stroke accuracy/repeatability.

Type	Series	Action	Bore size (mm)
Slides (Slide bearing)	CY1S-Z	Double acting	6, 10, 15, 20, 25, 32, 40

SMC – Magnetically Coupled Rodless Cylinder CY1

This magnetically coupled, space-saving cylinder permits a wide range of applications.

Type	Series	Action	Bore size (mm)
Slider (Ball bushing bearing)	CY1L	Double acting	6, 10, 15, 20, 25, 32, 40
Linear guide	CY1H	Double acting	10, 15, 20, 25
Linear guide	CY1HT	Double acting	25, 32
